Metal Pall Ring Column Tower Packing Stainless Steel 304 316L Pall Rings

• Overview
• Product Description
• Product Parameters
• Detailed Photos
• Packaging & Shipping
• Company Profile
• FAQ

Overview

Basic Info.

Model NO.	NX-MPR
Material	Stainless Steel
Type	Chemical Filling, Tower Internals
Structure Feature	Metallic Packing
Usage	Chemical Industry Product
Source	Metal
Product Name	Metal Random Packing Stainless Steel Pall Ring
Keywords	Metal Pall Ring
Thickness	0.3-1.0mm
Available Volume	>95%
Use	Tower Packing
Transport Package	Jumbo Bag+ Pallet
Specification	16mm 25mm 38mm 50mm 76mm
Trademark	Nanxiang
Origin	Pingxiang Jiangxi
HS Code	8419909000
Production Capacity	100m3/Month

Product Description

Introduction

Pingxiang Nanxiang Chemical Packing Co., Ltd was established in 2003, It is a professional manufacturer and exporter that has more than 20 years experience in Chemical Packing. We are located in West Section Hi-Tech Industry Park Pingxiang City, Jiangxi Province, with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world.

1.Who are we?

Product Description Metal Pall Ring, has features such as thin wall, heat resistant, high free volume, high capacity, low resistance, high separation efficiency and so on. It is especially suitable for rectification towers under vacuum to treat thermosensitive, decomposable, polymerizable or cokable systems. Pall rings packing shows its interior and exterior surface contact which is beneficial to resist plugging, nesting, and fouling all along in with the distribution of liquid and gas. Pall rings function with versatility, high resistance to fouling, high temperature, and can be easily soaked.Metal pall ring is an industry standard design media developed from the raschig ring and is used widely in allvariety of applications. By minimizing the number of contours and crevices that can cause liquid hold-up andpotential entrainment, the metal pall ring's geometry enables high gas and liquid transfer rates.Features: High free volume, large void space;low pressure drop; Top mass transfer performance High floating point;high separation efficiency. Excellent corrosion and heat resistance Easy to install or remove. RecyclableAdvantage: 1.A versatile packing used in distillation, absorption and other operations. 2.Used in both deep vacuum and high pressure towers. 3.Metal pall ring is high performance random packing successfully used in mass transfer towers both small and large diameter. It is frequently used in deep vacuum towers where low pressure drop is crucial and also high pressure towers where capacity significantly exceeds conventional traysApplication: It's available for rectification towers, cokable systems, crude distillation unit, desulphurization system, gas liquid separator.And it is widely used in petrochemical industry, chemical industry and environmental protection, etc.. Material:carbon steel, stainless steel304 304l 410 316 316l or Aluminum alloy, etc.

Product Parameters

Size (inch /mm)		Bulk Density (SS304 kg/m3)	Number (per m3)	Surface Area (m2/m3)	Free Volume (%)	Dry packing factorm-1
1/4"	6*6*0.3	900	4000000	904	88.6	1307.4
3/8"	10*10*0.3	480	768000	482	93.8	583.8
1/2"	13*13*0.3	420	410000	415	94.8	489.2
5/8"	16*16*0.3	348	201000	344	95.5	393.2
1"	25*25*0.4	288	53500	212	96.2	229.8
1"	25*25*0.5	367	53500	216	95	237.2
1"	25*25*0.6	439	53500	219	94.2	244.1
1.5"	38*38*0.4	193	15180	143	97.2	148.4
1.5"	38*38*0.5	246	15180	145	96.7	151.7
1.5"	38*38*0.6	328	15000	146	95.9	154.6
2"	50*50*0.5	185	6500	106	97.5	128.5
2"	50*50*0.7	315	6500	108	96.4	130.5
2"	50*50*0.9	380	6500	132.5	95.4	134.0
3"	76*76*0.8	265	1920	69	97.4	79.6
3.5"	901*90*1.0	224	1220	61	97.1	66.2

Detailed Photos

Packaging & Shipping

Package	Carton box, Jumbo bag, Wooden case
Container	20GP	40GP	40HQ	Normal order	Minimum order	Sample order
Quantity	25 M3	54 M3	68 M3	<25 CBM	1 M3	< 5 pcs
Delivery time	15 days	20 days	30 days	15 days	3 days	Stock
Comments	Customize package is acceptable

Company Profile Our main products are molecular sieve, activated alumina, ceramic ball, honeycomb ceramics, random and structured chemical packing in ceramic, plastic and metal material, can be used in all types of petrochemical chemical processes and environmental application. Our well-equipped facilities and excellent quality control throughout all stages of production enables us to guarantee total customer satisfaction. Besides, we have received ISO9001:2008 certificate, SGS report, and credible merchant of ******. As a result of our high quality products and outstanding customer service, we have gained a global sales network reaching seven Continents. Since its foundation, our company keeps living up to the belief of "honest selling ,best quality ,people-orientation and benefits to customers" We are doing everything to offer our customers with best services and best products .We promise that we will be responsible all the way to the end once our services begin. If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with you, also warmly welcome to visit our factory.
FAQ We located in Pingxiang City, known as "Hometown of Chemical Packing", established in 2003, have over 10 years export experience, there are 50-80 workers in our company. Products sell to Domestic Market (30%). Southeast Asia (15%), Mid East (10%), Europe (20%), South America (5.0%), North America (15%), Africa (5.0%). 2.How can we guarantee quality? We have QC during production, and after product finished Samples can provide before order Inspection can be done before shipment if needed 3.What can you buy from us? Plastic,ceramic,metal random and Structured tower packing, Ceramic Ball, Molecular Sieve, Silica Gel, Various kinds of ceramic bio ball for water treatment 4. What payment term can we do? We accept payment type like T/T, L/C, PayPal, MoneyGram, Western Union etc. 5. What services can we provide? Accept customized according to your requirements. Accept Delivery Terms: FOB,CFR,CIF,EXW,FCA,DDP,DDU,Express Delivery. Accept Payment Currency:USD,EUR;RMB No strict require on the MOQ, accept small order
